Plan: 60-03AB Bagatelle

Plan Specification
Total Square Footage: 5,235
Main Level: 5,235
Bonus: 824
Bedrooms: 4
Baths: 3 Half: 2
Garages: 4
Width/Depth: 106 ft / 122 ft
Foundation: Basement, Crawl Space, Slab
View typical construction drawing >
© copyright by designer
First Floor Plan:
First Floor Plan
© copyright by designer
Opt Second Floor Bonus:
Opt Second Floor Bonus
Similar plans: 51-03, 61-03
Add to Favorites
Purchase Plans
Get Your House Plans In Minutes!
NEW PDFs NOW!™ Plan packages available. Simply place your order, electronically sign the license agreement, and receive your PDFs within minutes in your inbox!
House Plan Pricing
PDFs NOW!™ $6,059.00
Foundation Options
$0.00
$350.00
$400.00
Plan Details
General House Information
1.5
Number of Stories:
106' 2"
Width:
122' 2"
Depth:
Single
Dwelling Number:
2nd Floor
Bonus Access:
Exterior Style
Luxury
Country
French Country
Southern
Traditional
Number of Rooms
4
Bedrooms:
3
Full Baths:
2
Half Baths:
Finished Square Footage
5,235 Sq. Ft.
Main Level:
5,235 Sq. Ft.
Total:
Unfinished Square Footage
1782 Sq. Ft.
Garage:
919 Sq. Ft.
Porch:
824 Sq. Ft.
Bonus Room:
Foundation
Basement
Crawl Space
Slab
House And Ceiling Heights
10
First Floor Ceiling:
9
Second Floor Ceiling:
29' 4"
Maximum House Height:
Framing Information
Stick
Roof Framing:
2x4
Exterior Wall Framing:
Roof Pitch
10/12
Primary:
15/12
Secondary:
Insulation (R)
Per IRC Climate Zones
GARAGE
Side
Garage Location:
4
Garage Size:
Attached
Feature:
Side-entry
Feature:
Key Features
• Guest Suite
• His and Hers Master Closets
• Master Bdrm Main Floor
• Walk-in Closet
• Front Porch
• Rear Porch
• Basement
• Crawlspace
• Slab
• Arches
• Bonus Room
• Dining Room
• Family Room
• Fireplace
• Formal LR
• Laundry 1st Fl
• Mud Room
• Open Floor Plan
• Butler's Pantry
• Kitchen Island
• Walk-in Pantry
• Suited for corner lot
